Square Rain Gutter Down Pipe Cold Roll Forming Machine K Span

Name: Square Rain Gutter Down Pipe Cold Roll Forming Machine K Span
Brand: CANGZHOU FMS
Price: 1 USD

Buy cheap Square Rain Gutter Down Pipe Cold Roll Forming Machine K Span product

Brand Name : CANGZHOU FMS

Model Number : Down Pipe Roll Forming Machine

Certification : ISO CE

Place of Origin : CHINA

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C, T/T, D/A, D/P

Supply Ability : 20 Sets Per Month

Delivery Time : 30 Working Days

Packaging Details : 20' FLC

Product Name : Square Rain Gutter Down Pipe Cold Roll Forming Machine K Span

Production Capacity : 8-15m/min

Cutting blade material : Cr 12 Mov

Thickness : 0.4-0.6mm

Touch Screen : Siemens brand or as the customer's requirements

Gross weight per unit product : 9500kg

Voltage : 380V 50Hz 3phases or as your requirement

Control system : PCL

Roll stages : 16 stages

Contact Now

Square Rain Gutter Down Pipe Cold Roll Forming Machine K Span

Square Rain Gutter Down Pipe Cold Roll Forming Machine K Span can bend the roll formed pipe, and let the drainpipe and the bending connect to be the whole.The product after roll forming has long working time than the tranditional ppc pipe, and not aging. It can make the project more integrate, and help to enhance the image of the all project.

Specification

Square Rain Gutter Down Pipe Cold Roll Forming Machine K Span parameter
Suitable roll forming material	Color steel sheet
Thickness	0.4-0.6mm
Frame design	Wall-plate-frame-design /New-stand-frame-design
Roll stages	16 stages
Material of forming roller	45# steel, CNC lathes, Hard Chrome Coated
Shafts Diameter	Φ75mm
Main motor power	7.5KW
Max. Line speed of roll former	15m/min (Higher speed is available, depends on the specification required by the buyer)
Hydraulic group power	4KW
Material of cutting blade	Cr12, hear treatment
Electric Standard	380V /50Hz/3PH or as per customer's requirements
Machine Dimensions	8850mm×1280mm×1550mm
Major Color of Machine Painted	RAL 5015 (Blue) or as per customer's requirements

Installation

During the installation and adjustment of the equipment, our engineers shall provide the training to the buyer’s personal request to operate and maintain the equipment. Including foundation construction, electrical works, hydraulic oil, safe operation, and non-standard safety items, testing material and etc.

Guarantee

The warranty will be maintenance, maintain in the guarantee period of 18 months starting from delivery. Because of the quality of equipment during the guarantee period, we will provide the parts free of charge, which is in the conditions of correct operation. (Natural disasters or factors which can’t be forced by human are excluded).

Payment terms

40% in advance

60% is paid before shipping

Square Rain Gutter Down Pipe Cold Roll Forming Machine K Span
